ZH-M4

点击放大图片
Loading Area: 1024*64, 256*256;
Totally pixel: 65536;
Output Port: 4*hub75;
Product introduction Download
I. Function Introduction:

1. Multi-platform control: Support PC, Android and IOS.
2. Fast transmission rate: Use HTTP protocol and data compression, data transmission is smaller and faster.
3. Background transmission efficient: Proprietary algorithm, small data size, higher efficiency.
4. Simple operation: Simple UI design, debugging and use do not affect each other, and zero learning cost.
5. Multilayer overlay processing: Background and foreground do not affect operational efficiency.
6. WiFi and U disk dual communication: Subtitle data can be transmitted through WiFi and U disk.
7. Support various indoor and outdoor unit board: HUB75E interface match with various kind of the unit board.
8. Support module manufacturers' line type loading: Support direct selection of module manufacturers' line type.
9. Support module line type automatic scanning: Line type automatic scanning.
10. Support program timing play, fixed time play, designated time play: The program can play at will.
11. Support rainbow word, background, pictures and other materials: Support all kinds of common materials.
12. Support user password function: In addition to WIFI password, the screen can be encrypted twice, which is more secure to use.
13. Support special chips: Such as ICN2038S.
14. Support external interface extension: Such as temperature, humidity sensor.


II. Detail Parameters

Operating system:
PC device support: XP, Win7, Win8 and Win10.
Mobile terminal support: Android(Android), IOS.
Display effect: support software dynamic background, magic run side overlay play.
Running type: phantom running, support the whole screen running/multi partition running/custom running.
Play type: support multi-program sequential play/timing play/fixed-length play/time-sharing play/lock single program play.
Adaptive range: support various 75E interface unit board.
Supporting software
PC side : LED player V5
Mobile terminal: LED Mobile (color), support multi-program editing/multi-area display/multi-language version.
Area type: subtitle/time/analog dial/temperature.
Communication mode: WIFI, stable speed; U disk, plug and play.
Sensor: temperature, humidity.
Clock: support multinational clock play, support jet lag Settings.
Working voltage: + 4.5v ~6V
Maximum power consumption: <1W
Operating temperature: -30°C~70°C


III. Loading Area

Model HUB Port Loading Area Storage
ZH-M4 4*hub 75E 1024*64  512*128  256*256
max width:1024; max height:256
8M
